Pre-painted Aluminum Sheet Coil - PVDF
MC Aluminum, as a professional aluminum processing manufacturer, provides the most popular colors of PVDF pre-painted aluminum coils and sheets. The aluminum substrate features an excellent painted surface, good cold formability, weldability, and outstanding corrosion resistance.
What is Pre-painted Aluminum Coil?
Pre-painted aluminum sheet coil refers to high-quality aluminum substrate that is coated with one or multiple functional layers of paint through an advanced roll coating process. This ensures that the aluminum coil already has the required decorative and weather-resistant properties before leaving the factory. Compared with traditional spray-coating methods, pre-painting achieves more uniform coating, stronger adhesion, and more stable surface performance, while also enabling mass production.
What is PVDF?
PVDF (Polyvinylidene Fluoride) coating is a premium metallic coating system developed with special ceramic pigments and fluoropolymer resins. It is designed for high-end applications where superior weather resistance and durability are required. PVDF coating systems usually come with a 30-year limited warranty from the paint manufacturer.
Besides PVDF-coated aluminum sheet coils, we also produce Polyester (PE) coated aluminum coils, which are more suitable for interior decoration and advertising display structures. These feature a wide variety of colors, good gloss, and come with a warranty of about 15 years.
PVDF Pre-painted Aluminum Coil Specifications
| Substrates | Aluminum 1100, 3003, 3004, 3105, 5005, 5052, 8011, 8079, etc. |
| Thickness | 0.08 - 4 mm |
| Width | ≤1800 mm |
| Length | 100 - 16000 mm |
| Coil Inner Diameter | 150 mm, 405 mm, 505 mm, 508 mm, 510 mm |
| Coating Type | PVDF (fluorocarbon coating) / 2-coat 1-bake or 3-coat 2-bake process |
| Coating Thickness | ≥25 μm (front), ≥5 μm (back) |
| Coating Hardness | Pencil hardness ≥ 2H |
| Diameter | 405 mm, 505 mm |
| Colors | RAL international color chart, white series, metallic series, dark colors, gold series (custom colors available) |
| Surface Finishes | Glossy, matte, embossed, textured coating |
| MOQ | 1-3 tons |
Key Features of PVDF Pre-painted Aluminum
1. Lightweight: About one-third the weight of steel.
2. Aesthetic appeal: Smooth, fine coating with uniform color and no shade variation. Can replicate wood or stone textures for a natural look.
3. Weather resistance: Excellent resistance to corrosion, UV rays, fading, and gloss loss, even in harsh environments. Service life can reach 25–30 years.
4. Processability: Strong adhesion and toughness of the coating enhances aluminum's ductility. Easy to cut, punch, and bend.
5. Eco-friendly: Free of harmful substances, compliant with green building standards. High paint utilization reduces waste.
6. Self-cleaning: Dense, smooth surface prevents dust accumulation; rainwater easily washes away dirt.
Applications of PVDF-coated Aluminum Coils
1. Architectural facades: Skyscrapers, stadiums, airports, museums, and other landmark buildings.
2. Metal roofing: Durable roofing systems for luxury villas, shopping centers, and industrial plants.
3. Aluminum honeycomb panels & composite panels: Widely used in interior and exterior decoration, ceilings, and elevator cabins.
4. Louvers & canopies: Sunshades and shelters exposed to long-term outdoor conditions.
5. Transportation sector: Rail transit, shipbuilding, and vehicle body decoration.
Why Choose Us?
Advanced Technology: Equipped with international continuous roll-coating production lines, ensuring uniform and stable coatings.
Quality Assurance: Manufactured in strict compliance with ASTM, EN, GB standards and certified by ISO9001 quality management system.
Diverse Options: Multiple aluminum alloys, thicknesses, colors, and surface finishes available.
Customization: OEM/ODM services to meet specific customer requirements.
Global Market Reach: Exported to Europe, the US, Southeast Asia, the Middle East, and Africa, widely recognized and trusted by customers.
